Operating Specifications | |
|---|---|
| Analysis Modes | Standard:TC, NPOC Option: TIC, TNb , TOCdiff, POC/VOC, |
| Ranges | TC/Carbon : 0-10; 0-200; 0-2,000; 0-10,000; with Dilution 0-50,000 mg/L; Wide Range: 0-200; 200-20,000 mg/L; |
| Options/Accessories | Leak Detection (for TC only), Sample Stream 2, Particulate Sampler, Air Box, Air Scrubber, Communication Box, Mounting Rack, PID Detector* (for POC/VOC) or ECD Detector* (for TNb) |
| Features | Auto Calibration, Dilution, Check Function, Auto Rinse, Connectivity (Remote Control), Predictive Maintenance |
| Precision | +/-2% End of Detector Range† |
| Linearity | R2 ≥0.997† |
| LOD | <1 ppm† |
| Analysis Time | 3-5 min typically |
| Smallest Inner Diameter (ID) | 2 mm smallest tubing diameter |
| Capacity | Up to 21 samples in duplicate with positive product controls |
| Salt Tolerance | 3-5% NaCl |
| Carrier Gas | CO2 free air < 1 ppm CO2 and <0.1 ppm hydrocarbon: 100-200 kPa @ 30-50L/hr flow rate (Optional: Air box) |
| Sample Temperature | 2-60 °C (35.6-140 °F) |
| Ambient Temperature | 2-40 °C (35.6-104 °F) |
| Minimum Sample Flow Rate | 100 mL/min without Particulate Sampler or 11.7-50 LPM (3.1-13.2 US gal/min) with Particulate Sampler |
| Drain | Gravity, No back pressure (< 7 kPa, 0.07 Bar, 1 psig) |
Analyzer Specifications | |
| Communication protocols | OPC UA, Modbus TCP/IP |
| Inputs | Digital Input (4) |
| Display | 7 in. Touch panel |
| Power | AC 110 – 230 V ±10 V 50/60 Hz, 400-600 VA |
| Alarm Relays | Warnings, errors, measurement limit, instrument status |
| Outputs | OPC UA, Ethernet, 4-20 mA (6) |
| Installation/Overvoltage Category | II |
| Available Configurations | Standard: Single-Stream; Option: Second Stream |
| Dimensions | 900 H x 644.3 W x 354.5 D mm (35.5 H x 25.4 W x 14 D in) |
| Weight | 55 kg, (121 lb) |
| Safety Certifications | CE, UL, CSA |
| Regulatory | DIN EN 1484 /ISO 8245, EPA 415.3, SM 5310B, ASTM D5173, HJ 501, DIN EN 12260 |
Environment | |
| Enclosure | Standard: IP-54; Option: ATEX Zone 1 & 2 T4, IECEx Zone 1 & 2 T4, C1D2 |
| Maximum Relative Humidity | Up to 85%, non-condensing |
可以用於廢水、工藝水、冷卻水、環境樣品和大部分工業過程水樣品的分析，包括：
