0.5 to 300 grams

80 grams to 8.6 kilograms

50 – 1000 mL/min

100 psi (6.89 bar)

200 – 400 nm (200 – 800 nm optional) with single, dual, or All-wavelength collection. Accepts external detector input.

Binary, high pressure solvent mixing with linear, step, or isocratic capability. Two solvent inlets.

<2% full scale from 0.2 to 1.0 liter/min.

Automated injection with options of solid load cartridges, liquid load, or direct injection.

10.4 in (26.7 cm) touchscreen

On-screen method development and control with PeakTrak software.

Up to four fraction collectors, fractionation valve, or manual collection.

Patented, active level sensing for inlet and waste containers.

(W x D x H) 18.5 x 17.9 x 28.1 in (47 x 43.5 x 71.4 cm)

65 lbs (29.5 kg)

100 VAC 50 Hz, 117 VAC 60 Hz, 234 VAC 50 Hz

• Static-dissipative tubing throughout
• Vapor sensor for internal leak detection
• Overpressure sensor
• Active solvent and waste level sensing
• Audible alarm when user intervention is required

CE
