Specifications & Advantages
MagnoPod magnet/sample probe is a separate unit
- Remote operation for use in hazardous and sensitive environments
- Field strength range: 10 MHz – 15 MHz for increased sensitivity
- Flow-through modification*
Highly-customizable, user-selectable pulse sequencing
- Phase cycling, composite pulses, two-channel RF and 3D shaped gradients
- Robust self-diffusion measurement* from water to viscous liquids: 10-9 – 10-13 m2 s-1
- Droplet sizing analysis*
- Polymer characterization in solution and melts* (through hydrodynamic radius)
- 1D, 2D and 3D imaging*
- Customizable by software pulse programming interface*
Powerful MagnoSoft software
- Based on a dedicated dual-core ARM9 processor running Debian
- Easily upgradeable and flexible by direct Ethernet access
Programable temperature control
- Optional upgrade to a wider continuous range of 10 °C – 80 °C
MagnoPod is easily exchangeable
- Different nuclei (7 Li, 19F, 31P) use convenient separate pods
Shorter RF pulses
- 90° pulse of < 5 μs
- Measurement of solid materials*
- Useful for highly paramagnetic samples
- Direct measure of the solid/liquid ratio
Works with four different size OD regular NMR tubes
- 2 mm (highest resolution), 4 mm (standard resolution), 8 mm (lower resolution) and 10 mm (lowest resolution)
- Resolution: 200 ppm (or better) with 4 mm tube**
Access to customized pulse sequencelibrary and analysis software
Access to expert advice on all aspectsof NMR and its applications
* In development
** Depending on choice of magnet
