Specifications

• The reactor specification is as follows:
• The working (liquid) volume of the standard reactor is 15 ml
• The gas volume is approximately 4ml.
• The maximum gas supply pressure is 30 bar
• The maximum liquid reaction pressure is 30 bar
• The maximum operating temperature is 150°C

Constraints

• The gas reactor has the following restrictions:
• It is not acid resistant (the liquid wetted parts of the reactor include 316 stainless steel).
• The differential between the gas and liquid pressures should not exceed 8 bar except when the temperature is < 60°C.
• Compatible gases include (but are not limited to) CO, H2, O2 . Slower diffusion will be experienced with gas with much larger molecules.
