| 產品特點

• 小巧易攜，方便擺放
• 5 吋觸控螢幕
• 智能採樣模式支持連續、循環和遠程採樣
• 審計追蹤允許記錄事件並提供文件，以便在出現數據完整性問題時進行進一步分析
• 一鍵報告匯出和列印功能
• 與 APC 和 BAMS 的無線連接支持觸發式採樣

• 28.3 L/min ≥ 7 hours (16.98 m³)
• 100 L/min ≥ 7 hours (60 m³）
• 200 L/min ≥ 3 hours (48 m³）

• ± 4% (28.3 L/min)
• ± 2.5% (100 L/min)
• ± 3% (200 L/min)

| 採樣

• 清晰明確的採樣流程
• 智能採樣模式支持連續、循環和遠程採樣
• 5 吋觸控螢幕

| 數據

• 可用的審計記錄提供所有關鍵事件的記錄
• 一鍵報告導出和打印
• 與 APC 和 BAMS 的無線連接支持自動取樣

SPECIFICATIONS

• FLOW RATE： 28.3L/min, 100L/min, 200L/min
• FLOW RATE CONTROL:   Built-in mass flow meter
• FLOW RATE ACCURACY： ±4% (28.3L/min), ±2.5%（100L/min), ±3%（200L/min）
• SAMPLING PLAN： 20,000 groups, 20,000 rooms, 500 locations for each room, up to 20,000 locations
• SAMPLING VOLUMES： 1-6,000L
• DELAY： 0-23 hours 59 minutes 59 seconds
• CYCLES： 1-999cycles
• INTERVAL： 00:00:00，0-23 hours 59 minutes 59 seconds
• SAMPLING HEAD： Φ0.32mm*280holes (28.3L/min), Φ0.60mm*280holes (100L/min), Φ0.70mm*400holes (200L/min)
• EXHAUST：Built-in HEPA filter (filter efficiency: ＞99.999% @0.3μm )
• DIMENSIONS (HxWxD)： 186x115x204mm/ 7.32×4.53×8.04 in (without foot mat)
• WEIGHT： 3.6kg (7.9lbs) with battery
• EXTERNAL SURFACE： 316L stainless steel
• POWER： 24V±10% AC adapter
• BATTERY： 10.8V, 6800mAh rechargeable lithium battery, 28.3&100L/min:running for over 7 hours, 200L/min:running for over 3 hours
• DATA STORAGE： 20.000 sets of sample records
• DISPLAY： 5″ capacitive touch screen
• LANGUAGE： Chinese, English
• CALIBRATION FREQUENCY： Recommend once a year
• OPERATING CONDITIONS：5-35℃(41-95℉), 5-90%RH non-condensing
• STORAGE CONDITIONS： 0-40℃(32-104℉), 5-95%RH non-condensing
• SAFETY： EN 61010-1:2010+A1:2019, EN 61326-1:2013, EN IEC 61326-1:2021, EN 61000-6-1:2007, EN 61000-6-3:2007+A1
• WARRANTY： 24 months (calculated from the date of product activation or 6 months after the date of manufacture, whichever comes first)
